The rugged construction and versatility of the Bloom 1000 Series makes it adaptable to a wide range of applications, according to the manufacturer.

Bloom 1000 Series direct drive winches are used for industrial pulling and hoisting applications including small cranes, rear load waste packers, drill rigs, fishing boats, marine craft, mining and logging operations, flat bed trailers, air freight pullers, rear of cab and front mounting on 1/2 to 1-1/2 ton trucks.

The Bloom 1000 Series winches are rated up to 12,000 lbs. and are equipped with a sliding clutch to allow free-spooling of the drum for industrial pulling applications including rear of cab and front mounting on 1/2 to 1-1/2 ton trucks, flat bed trailers, factory material handling, mining and logging operations, air freight pullers, off the road tractors, aboard ships and boats. Both the Bloom 1000 Series and 1000C Series are available with a hydraulic brake, and may be ordered galvanized.

Standard Features

GEAR CASE – Made of high strength cast iron. Completely sealed for oil enclosed operation and to keep dirt out.

WORM SHAFT – One-piece alloy steel hardened and ground for extra durability. Compact design allows hydraulic motor to be coupled directly to worm.

WORM GEAR – High tensile aluminum-nickel alloy bronze. Optimum lead and pressure angles transmit maximum power to the drum.

GEAR RATIO – 20:1 standard, 10:1, 27:1, 40:1 optional ratios provide optimum efficiency in power and speed.

BEARINGS – Worm gear and worm shaft run on tapered roller bearings. Outer end housing has sealed ball bearing.

DRUM SHAFT – 1-1/2” diameter heat -treated alloy steel minimum tensile strength 150,000 psi.

CABLE DRUM – Tough all steel construction resists breakage or warping.

CAUTION: This winch model does not include any kind of holding brake. For applications that require a holding brake, Bloom recommends the 1000H, 1000K, or 1000W series winches with automatic hydraulic safety brakes.
